In summary, two conditions are required to achieve the function of playing dual - layer Dolby Vision by replacing the SOC. First, the original set - top box can start CE smoothly. Second, the chip with the J/K suffix that is replaced must be an unencrypted chip. It is known that S905L3A( - B) and S905X2 can be replaced with S905X2 - J/K/JU, and the same applies to S905X4.
where are you buying these SOC’s, can anyone buy them? thanks for showing it can be done
In secend hand market 闲鱼.but before buying,u should confirm that the soc is unlocked.this way is much cheaper than buy from alibaba etc.someone in the second market 闲鱼 can do all the things for u by paid.it’s about ¥340 ,u can get a 4+32 modified box with s905x2-j/k or s905x4-ju.
1 Like
that’s amazing! thanks for sharing the details! love hearing about cool stuff like this!
Hi there. I just brought the Freebox. But it can not boot CE. How did you successfully start CE with this box. Thanks!
First, confirm that your device is a Freebox Pop. Next, ensure that you have enabled Developer Options and ADB. Then, you can either install the ‘reboot to libreelec.apk’ or use the ADB command ‘adb update’.
important u should use the right dtb.for freebox pop is s905x2_2g.dtb
there are some ways for u.
https://discourse.coreelec.org/t/reboot-to-coreelec-apk
Hello
I got one of this from Xianyu model No. is SEI500BS(s905x2-j)and managed use adb installed and boot to coreelec successfully. But it couldn’t play any video no matter what size or formats. So far I tired ce-ng 20.5 21.1 also nightly version as well. The dtb file which Im using is s905x2 2g and everything work perfectly (Ethernet BT Wifi). I have no idea how to fix it. I also tested with android version kodi and turned out all videos play just fine. Please help. Thank you.
Hit play button then nothing shows up. Some video is black screen and play few seconds audio. I tired h264 h265 codecs / sdr hdr dv all kinds of videos.
Ok I found the problem. I must disable “hardware acceleration amcodec” in player setting. However this will make videos hardly to play. No hardware acceleration at all.
This is the log:
2024-11-23 22:23:31.814 T:3848 info : VideoPlayer::OpenFile: ftp://192.168.50.1:21/sdb1/电影/The.Wild.Robot.2024.2160p.4K.WEB.x265.10bit.AAC5.1-[YTS.MX].mkv
2024-11-23 22:23:31.815 T:10008 info : Creating InputStream
2024-11-23 22:23:31.956 T:10008 info : Creating Demuxer
2024-11-23 22:23:31.961 T:10008 info : Opening stream: 0 source: 256
2024-11-23 22:23:31.962 T:10008 info : Creating video codec with codec id: 173
2024-11-23 22:23:31.962 T:10008 info : CBitstreamConverter::Open bitstream to annexb init
2024-11-23 22:23:31.964 T:10008 info : DVDVideoCodecAmlogic: Opened Amlogic Codec
2024-11-23 22:23:31.964 T:10008 info : Creating video thread
2024-11-23 22:23:31.964 T:10011 info : running thread: video_thread
2024-11-23 22:23:31.965 T:10008 info : Opening stream: 1 source: 256
2024-11-23 22:23:31.965 T:10008 info : Finding audio codec for: 86018
2024-11-23 22:23:31.967 T:10008 info : CDVDAudioCodecFFmpeg::Open() Successful opened audio decoder aac
2024-11-23 22:23:31.967 T:10008 info : OpenStream: Allowing max Out-Of-Sync Value of 50 ms
2024-11-23 22:23:31.967 T:10008 info : Creating audio thread
2024-11-23 22:23:31.968 T:10012 info : running thread: CVideoPlayerAudio::Process()
2024-11-23 22:23:31.968 T:10008 info : Opening stream: 2 source: 256
2024-11-23 22:23:31.968 T:10008 info : CDVDSubtitlesLibass: Using libass version 1701000
2024-11-23 22:23:31.968 T:10008 info : CDVDSubtitlesLibass: Creating ASS library structure
2024-11-23 22:23:31.968 T:10008 info : CDVDSubtitlesLibass: Initializing ASS Renderer
2024-11-23 22:23:31.969 T:10008 info : CDVDSubtitlesLibass: Initializing ASS library font settings
2024-11-23 22:23:31.999 T:10008 info : CDVDSubtitlesLibass: Creating new ASS track
2024-11-23 22:23:32.000 T:10011 info : CDVDVideoCodecAmlogic::AddData: Open decoder: fps:24000/1001
2024-11-23 22:23:32.010 T:10012 info : Creating audio stream (codec id: 86018, channels: 6, sample rate: 48000, no pass-through)
2024-11-23 22:23:32.040 T:3901 info : CActiveAESink::OpenSink - initialize sink
2024-11-23 22:23:32.240 T:3901 info : CAESinkALSA::Initialize - Configure simple control for “AUGESOUND”
2024-11-23 22:23:32.240 T:3901 info : CAESinkALSA - Use card “hw:0” and set codec format “2 CH PCM”
2024-11-23 22:23:32.242 T:3901 info : CAESinkALSA - Set Spdif to HDMITX to “Spdif”
2024-11-23 22:23:32.242 T:3901 info : CAESinkALSA - Set codec for “Audio spdif_b format”
2024-11-23 22:23:32.242 T:3901 info : CAESinkALSA - Set codec for “Audio spdif format”
2024-11-23 22:23:32.242 T:3901 info : CAESinkALSA::Initialize - Attempting to open device “surround71:CARD=AMLAUGESOUND,DEV=0”
2024-11-23 22:23:32.249 T:3901 info : CAESinkALSA::Initialize - Opened device “surround71:CARD=AMLAUGESOUND,DEV=0”
2024-11-23 22:23:32.250 T:3901 info : CAESinkALSA::InitializeHW - Your hardware does not support AE_FMT_FLOAT, trying other formats
2024-11-23 22:23:32.250 T:3901 info : CAESinkALSA::InitializeHW - Using data format AE_FMT_S24NE4
2024-11-23 22:23:42.623 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5466ms (11:Resource temporarily unavailable)
2024-11-23 22:23:47.855 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5232ms (11:Resource temporarily unavailable)
2024-11-23 22:23:52.863 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5005ms (11:Resource temporarily unavailable)
2024-11-23 22:23:58.483 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5617ms (11:Resource temporarily unavailable)
2024-11-23 22:24:03.911 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5428ms (11:Resource temporarily unavailable)
2024-11-23 22:24:08.931 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5017ms (11:Resource temporarily unavailable)
2024-11-23 22:24:13.943 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5010ms (11:Resource temporarily unavailable)
2024-11-23 22:24:18.959 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5013ms (11:Resource temporarily unavailable)
2024-11-23 22:24:24.387 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5425ms (11:Resource temporarily unavailable)
2024-11-23 22:24:30.023 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5635ms (11:Resource temporarily unavailable)
2024-11-23 22:24:35.240 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5214ms (11:Resource temporarily unavailable)
2024-11-23 22:24:40.687 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5444ms (11:Resource temporarily unavailable)
2024-11-23 22:24:45.894 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5207ms (11:Resource temporarily unavailable)
2024-11-23 22:24:51.131 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5236ms (11:Resource temporarily unavailable)
2024-11-23 22:24:56.154 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5020ms (11:Resource temporarily unavailable)
2024-11-23 22:25:01.370 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5213ms (11:Resource temporarily unavailable)
2024-11-23 22:25:06.419 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5046ms (11:Resource temporarily unavailable)
2024-11-23 22:25:11.635 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5213ms (11:Resource temporarily unavailable)
2024-11-23 22:25:16.663 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5025ms (11:Resource temporarily unavailable)
2024-11-23 22:25:21.899 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5233ms (11:Resource temporarily unavailable)
2024-11-23 22:25:27.319 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5417ms (11:Resource temporarily unavailable)
2024-11-23 22:25:32.339 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5020ms (11:Resource temporarily unavailable)
2024-11-23 22:25:37.562 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5220ms (11:Resource temporarily unavailable)
2024-11-23 22:25:44.255 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 6689ms (11:Resource temporarily unavailable)
2024-11-23 22:25:50.735 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 6479ms (11:Resource temporarily unavailable)
2024-11-23 22:25:56.170 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5435ms (11:Resource temporarily unavailable)
2024-11-23 22:26:01.407 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 5234ms (11:Resource temporarily unavailable)
2024-11-23 22:26:07.499 T:10011 error : CAMLCodec::GetPicture: time elapsed since last frame: 6072ms (11:Resource temporarily unavailable)
maybe for the same reason,check if it is rev d.
I have no clue whether this is rev.d or not. I returned this sei500 tivo estream box to seller anyway.
Well, this is a X2 anyway, isn’t it?
Hi Simon, thanks for your answer and help. I have a Freebox pop too and i have enabled the developer mode and usb debugging. But i tried to boot with coreelec in usb stick my tv stuck in black screen (bootloop)… I use “g12a_s905x2_2g.dtb” renamed by “dtb.img”
check if the file name is dtb.img.img
as what you post，it implied that you didn’t use reboot_to_coreelec.apk
The file name is “dtb.img”. But, i tried with a microSD card and now my tv stuck on blackscreen without bootloop. My Freebox Pop is not rooted (secure boot ON) and not possible to access to bootloader mode. I have a all files a previous firmware (boot.img/bootloader.img/etc…) but I don’t know how to root the device for use CoreELEC…
I use reboot_to_coreelec.apk from box but still blackscreen…
I try to bootloader unlock my box (Freebox pop has lock the multiboot/boot on usb or sd). I got various files (01_dtbdump_Amlogic.dtb, dts1, boot.bin, bootloader.bin, dtb.bin, dtbo.bin).
I’m still looking for a way to run coreelec on this one. I think you really need to unlock the bootloader.
I have never encountered this issue before, and I’m sorry I can’t provide more assistance.
Finally, I decided to buy an AM6B+.
